Product Description
Our Automatic Sleeve Shrink Labeling Machine is a high-speed, reliable labeling solution designed for small PET bottles used in water, beverage, and food industries. It applies shrink sleeves (labels) neatly and tightly around bottles using heat shrinkage technology, ensuring a professional, tamper-evident, and visually appealing finish.
The machine integrates multiple functions including label feeding, cutting, positioning, and shrinking into one continuous process. It supports various label materials such as PVC, PET, OPS, and OPP, and can accommodate bottles with diameters ranging from 28mm to 125mm. With production speeds of up to 500 bottles per minute (depending on label length), this machine is ideal for small to medium-scale bottling plants seeking efficiency, precision, and low maintenance.
Constructed with high-quality stainless steel and equipped with a PLC control system, the machine offers stable performance, easy operation, and quick changeover between different bottle sizes and label lengths. Its compact design saves floor space while delivering high output and consistent labeling quality.
Key Features
1. High-Speed Performance
The machine delivers standard speeds of 150 to 500 bottles per minute (based on 100mm label length). Shorter labels allow even higher speeds, meeting diverse production requirements.
2. Versatile Compatibility
Supports a wide range of bottle diameters (28mm–125mm) and label lengths (30mm–250mm). The system accommodates common label materials including PVC, PET, OPS, and OPP, making it suitable for various product lines.
3. Precision Cutting & Application
The cutting system ensures accurate label length with minimal waste. The shooting mechanism places labels consistently without skewing or wrinkling, ensuring a professional appearance.
4. Efficient Shrinking Oven
The steam-heated shrinking oven provides uniform heat distribution, ensuring smooth, tight shrinkage around bottles of different shapes and sizes. Steam consumption is approximately 50 kg/hour at 1 kg/cm² pressure.
5. Stable & Durable Construction
Built with high-quality materials, the main frame and contact parts are designed for long-term operation in humid and demanding environments. The machine operates with low vibration and minimal noise.
6. Easy Operation & Quick Changeover
The touchscreen interface allows operators to adjust parameters quickly. Changing between different bottle sizes or label lengths can be done in minutes, reducing downtime and improving production flexibility.
7. Flexible Power Supply
Available in both 220V single-phase and 380V three-phase configurations, accommodating different factory power setups.
Company Profile
Shine Dew Technology focuses on water, beverage, and packaging equipment projects, covering standalone machines, complete lines, engineering planning, and after-sales coordination. For products such as 5 Gallon ISB molding machines, our team supports solution matching from equipment selection to project delivery, helping customers reduce communication cost across procurement, installation, and production start-up.
We work with customers on equipment selection, line matching, technical communication, and follow-up service, so upstream bottle manufacturing can connect more smoothly with downstream washing, filling, capping, and packaging systems.
Suitable Applications
- Small PET bottles – 300ml, 500ml, 600ml, 1L, 1.5L
- Bottled water, mineral water, purified water
- Beverage bottles – juice, tea, sports drinks
- Dairy products and liquid food packaging
- Cosmetics and personal care containers
- Pharmaceutical and chemical product bottles
Logistics Information
- Standard export packing is prepared according to machine structure and transport safety requirements.
- Shipping method can be arranged by sea, rail, or combined logistics based on destination and delivery schedule.
- We can support shipment documents, loading coordination, and installation preparation before arrival.
Parameter Table
The following specifications can be used to review model configuration, production capacity, and project matching requirements.
| Model: |
SD-150 |
|---|---|
| Power Supply – Main Machine | AC220V 50/60Hz, 1.5–2kW (single phase) or AC380V 50/60Hz (three phase) – optional |
| Power Supply – Shrinking Oven | AC380V 50/60Hz, 4kW (three phase) |
| Production Speed | Standard 150–500 bottles/minute (based on 100mm label length; speed varies with label length) |
| Applicable Bottle Diameter | 28mm – 125mm |
| Applicable Label Length | 40mm – 180mm |
| Applicable Label Thickness | 0.035mm – 0.10mm |
| Label Materials | PVC, PET, OPS, OPP |
| Steam Consumption | Approx. 50 kg/hour |
| Steam Pressure | 1 kg/cm² |
| Main Machine Dimensions (L×W×H) | 2440 × 1000 × 2200 mm |
| Steam Oven Dimensions (L×W×H) | 2000 × 500 × 1600 mm |
